ZQ COMBINATION CLEANER

Z0 series cleaning to stone combination screen is widely used in rice, millet, wheat, corn, beans, peanuts, feed and foodprocessing plants used as raw grain cleaning. Not only can clean up the large and small and light impurities in raw grain also cleanup the sand at the same time, achieve the goal of net stone. The machine is used together with the corresponding fan, poweredby vibrating motor, vibrating motor to produce vibration force, make the reciprocating vibration sieve body, This machine havethree layers of screen surface, according to different raw grain configuration screen hole size. Ordering (user) the upper screensurface cleaning out the big miscellaneous. such as big rocks, straw, branches, etc. Middle screen surface will be smaler than thescreen hole size of the smallimpurities, such as smaller than grains of crushed stone, sand, soil and so on from the screen holeleakage unleashed closed, The lower sieve is dedicated to do bump stainless steel wire mesh, in under the action of wind, pavedwith stone screen material in a suspended state, wind according to the production and material type is changed from air volumeadjustment plate. Material from the discharging mouth eduction, sand from the stone mouth eduction. The machine due to thevibration motor, when starting and stopping, has more than ten seconds, the normal working state is stable, noise is very small.
